- Size: 37m*30m *15m
- Place of Origin: Taian
- Brand Name: HONGJIAN
- Model Number: LB1000
- Weight: 130000.000 kg
Components of Asphalt Mixing Plant LB1000
Item | Description | Qty. (set) |
01 | Cold Aggregate Batching Machine and Feeders Group of four components, unit capacity of the aggregate hopper is 8M³ (full hopper), total capacity is 32M³; Adopts imported variable-frequency governor Continuous dosing belt & and driving reduction motor group, group of 4 units; The electric vibrato: 2 units | 1 |
02 | Feeding belt conveyor | 1 |
03 | The Drying Drum Ø1540×6680 MM, the running speed: 11.3 RPM; Cylinder on frame, Rotation-driven through electric motor and reduction box, The heat-preservation is 50mm rack wool and stainless steel | 1 |
04 | Chinese famous brand oil burners( Imported oil burner or gas burner are optional) Fuel: Heavy oil, diesel oil and residual oil. | 1 |
05 | Cyclone dust collector | |
06 | Wet dust filter (Bag dust filter is optional) | |
07 | The hot aggregate elevator: capacity 100 T/H | 1 |
08 | The filler bin, the capacity of screw conveyor: 20T/H | 1 |
08 | The vibrating screen unit 4 grades, capacity 100T/H | 1 |
09 | The hot aggregate storage bin 4 units, the total volume is 10.9 M³ | 1 |
10 | The weighing devices The weighing unit for powder, aggregate and bitumen (each has one unit) | 1 |
11 | The mixing tower The main tower with supporting legs, repairing platform and guardrail | 1 |
12 | The mixer Capacity: 1000KG/batch, the motor power: 22KW*2 | 1 |
13
| Vibration screen | |
14 | Asphalt supply system and heating system 2 units of bitumen storage tank and heat-conducting oil system(Optional) | |
15 | Pneumatic control system | 1 |
16 | Electric control system | |
17 | Control room | |
18 | 30ton bottom-set finished mixture storage tank (Optional) | 1 |
- Size: 37m*30m *15m
- Place of Origin: Taian
- Brand Name: HONGJIAN
- Model Number: LB1000
- Weight: 130000.000 kg
Components of Asphalt Mixing Plant LB1000
Item | Description | Qty. (set) |
01 | Cold Aggregate Batching Machine and Feeders Group of four components, unit capacity of the aggregate hopper is 8M³ (full hopper), total capacity is 32M³; Adopts imported variable-frequency governor Continuous dosing belt & and driving reduction motor group, group of 4 units; The electric vibrato: 2 units | 1 |
02 | Feeding belt conveyor | 1 |
03 | The Drying Drum Ø1540×6680 MM, the running speed: 11.3 RPM; Cylinder on frame, Rotation-driven through electric motor and reduction box, The heat-preservation is 50mm rack wool and stainless steel | 1 |
04 | Chinese famous brand oil burners( Imported oil burner or gas burner are optional) Fuel: Heavy oil, diesel oil and residual oil. | 1 |
05 | Cyclone dust collector | |
06 | Wet dust filter (Bag dust filter is optional) | |
07 | The hot aggregate elevator: capacity 100 T/H | 1 |
08 | The filler bin, the capacity of screw conveyor: 20T/H | 1 |
08 | The vibrating screen unit 4 grades, capacity 100T/H | 1 |
09 | The hot aggregate storage bin 4 units, the total volume is 10.9 M³ | 1 |
10 | The weighing devices The weighing unit for powder, aggregate and bitumen (each has one unit) | 1 |
11 | The mixing tower The main tower with supporting legs, repairing platform and guardrail | 1 |
12 | The mixer Capacity: 1000KG/batch, the motor power: 22KW*2 | 1 |
13
| Vibration screen | |
14 | Asphalt supply system and heating system 2 units of bitumen storage tank and heat-conducting oil system(Optional) | |
15 | Pneumatic control system | 1 |
16 | Electric control system | |
17 | Control room | |
18 | 30ton bottom-set finished mixture storage tank (Optional) | 1 |
