01

Cold Aggregate Batching Machine and Feeders

Group of five components, unit capacity of the aggregate hopper is 15M³, total capacity is 75M³;

Adopts imported variable-frequency governor

Continuous dosing belt & and driving reduction motor (7.5 KW)

The electric vibrator: 2 units

1

02

Feeding belt conveyor

Production capacity:≥300 t

1

03

The Drying Drum

Ø2500×10188 MM, Thickness of shell: 16 mm

Cylinder on frame, Thickness of blade: 8mm

Rotation drive through electric motor and reduction box,

The heat-preservation is 50mm rack wool and stainless steel

1

04

Burner :China brand, Italy brand or Canada brand burners

Fuel kinds :oil,gas or coal

According to customer requirement

1

05

Cyclone dust collector

06

Bag dust collector

07

The hot aggregate elevator: capacity 320 T/H

1

08

The filler bin: 44 M³, powder tank truck transport the powder through pneumatic.

Recycling powder bin:29 M³

1

09

The vibrating screen unit

5 layer one set, capacity 260T/H

Vibration frequency: 960 r.p.m

1

10

The hot aggregate storage bin

5 numbers, the total volume is 80t

Insulation way: 50 mm thick insulation rock wool

1

11

The weighing devices

The weighing unit for powder, aggregate and bitumen (each has one unit)

1

12

The mixing tower

The main tower with supporting legs, repairing platform and guardrail

1

13

The mixer

Capacity: 3000 KG/BACH

Discharging door: controlled by cylinder, rotary feeding door

1

14

Asphalt supply system and heating system

Five units 30ton asphalt tank , one unit 10 discharging bitumen pool.

with 800000kcal/h thermal oil heater (coal fuel or oil fuel)

15

Pneumatic control system

1

16

Electric control system :

Siemens PLC control ,Main electric parts :Siemens or Schneider brand

Automatic and Manual control mode

17

Control room: 6.5 m(length)×2.25 m(width)×2.5 m(height)

18

mixture storage tank optional for customers(100t bottom type or 160t side type)

1
